Sparkle Intel Arc B580 TITAN OC 12 GB GDDR6 Luna Edition

Datablad

• Length 315 mm
• Package type Box
• Power consumption (typical) 200 W
• Number of slots 2.2
• Maximum resolution 7680 x 4320 pixels
• Windows operating systems supported Windows 10
• Processor frequency 2740 MHz
• DisplayPort version 2.1
• Dual Link DVI No
• HDMI version 2.1
• HDMI ports quantity 1
• Interface type PCI Express x8 4.0
• Number of fans 3 fan(s)
• Cooling type Active
• Minimum RAM 8000 MB
• Supplementary power connectors 1x 8-pin
• DisplayPorts quantity 3
• Graphics processor Arc B580
• Graphics processor family Intel
• Graphics card memory type GDDR6
• Discrete graphics card memory 12 GB
• Memory bus 192 bit
• OpenCL version 3.0
• DirectX version 12 Ultimate
• OpenGL version 4.6
• Memory bandwidth (max) 456 GB/s
• Minimum system power supply 600 W
• TV tuner integrated No
• CUDA No
• Maximum displays per videocard 4
• Ray accelerators 20
• Parallel processing technology support Not supported
• Power supply location Top
• Product colour White
• Height 117 mm
• Depth 44 mm
• Minimum system requirements PCI-Express compliant MB with one x16 PCIe slot
• Xe-cores 20
• Intel® Xe Matrix Extensions (Intel® XMX) Engines 160
• NPU performance up to 233 TOPs

Särskilda hänvisningar

• ean13 4711342290788
