Intel Xeon Gold 5416S processor 2 GHz 30 MB Tray

Datablad

• Harmonized System (HS) code 8542310001
• Export Control Classification Number (ECCN) 5A992C
• Commodity Classification Automated Tracking System (CCATS) G180729
• Processor model 5416S
• Processor manufacturer Intel
• Processor family Intel® Xeon® Gold
• Processor cores 16
• Maximum internal memory 4 TB
• Thermal Design Power (TDP) 150 W
• Status Launched
• Launch date Q1'23
• Use conditions Server/Enterprise
• Market segment Server
• ECC Yes
• PCI Express slots version 5.0
• Processor cache 30 MB
• Processor threads 32
• Processor boost frequency 4 GHz
• Processor generation Intel Xeon Scalable 4th Gen
• On-board graphics card model Not available
• Discrete graphics card model Not available
• On-board graphics card No
• Discrete graphics card No
• Intel Software Guard Extensions (Intel SGX) Yes
• Embedded options available No
• Intel Trusted Execution Technology Yes
• Intel Virtualization Technology for Directed I/O (VT-d) Yes
• Intel Virtualization Technology (VT-x) Yes
• Intel VT-x with Extended Page Tables (EPT) Yes
• Execute Disable Bit Yes
• Intel 64 Yes
• Processor socket LGA 4677 (Socket E)
• Memory channels Octa-channel
• Processor codename Sapphire Rapids
• Intel® AES New Instructions (Intel® AES-NI) Yes
• Intel® Hyper Threading Technology (Intel® HT Technology) Yes
• System bus rate 16 GT/s
• Processor operating modes 64-bit
• Stepping S3
• Memory types supported by processor DDR5-SDRAM
• Maximum internal memory supported by processor 6 TB
• Maximum number of PCI Express lanes 80
• Processor ARK ID 232396
• Intel® OS Guard Yes
• Intel® Turbo Boost Technology 2.0
• Supported instruction sets AMX
  AVX
  AVX-512
  AVX 2.0
  SSE4.2
• Scalability 2S
• Processor package size 77.5 x 56.5 mm
• Processor base frequency 2 GHz
• Intel® Transactional Synchronization Extensions Yes
• Intel® Boot Guard Yes
• Intel® Speed Shift Technology Yes
• Mode-based Execute Control (MBE) Yes
• Intel® Control-flow Enforcement Technology (CET) Yes
• Intel® Total Memory Encryption Yes
• Intel® Optane™ DC Persistent Memory Supported Yes
• Maximum Enclave Size Support for Intel® SGX 128 GB
• Number of UPI links 3
• Memory speed (max) 4400 MHz
• Tcase 79 °C
• Intel® Crypto Acceleration Yes
• Intel® Resource Director Technology (Intel® RDT) Yes
• Intel® Platform Firmware Resilience Support Yes
• AVX-512 Fused Multiply-Add (FMA) units 2
• Intel® Speed Select technology - Performance Profile (Intel® SST-PP) Yes
• Intel® Run Sure Technology Yes
• Intel® Speed Select Technology - Base Frequency (Intel® SST-BF) Yes
• High priority cores 4
• High priority core frequency 2.1 GHz
• Low priority cores 12
• Low priority core frequency 1.7 GHz
• Package carrier E1B
• DTS Max 90 °C
• Intel® Dynamic Load Balancer (DLB) 2 default devices
• Intel® Data Streaming Accelerator (DSA) 1 default devices
• Intel® Advanced Matrix Extensions (AMX) Yes
• Intel® QuickAssist Technology (QAT) 2 default devices
• Intel® QuickAssist Software Acceleration Yes
• Intel® On Demand Feature Activation Yes
• Warnings The product should be used in accordance with the manufacturer's instructions to avoid damage.
• Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes
