Intel Xeon Gold 6346 processor 3.1 GHz 36 MB Tray

Datablad

• Harmonized System (HS) code 85423119
• Cooler included No
• Export Control Classification Number (ECCN) 5A992CN3
• Commodity Classification Automated Tracking System (CCATS) G178966
• Processor model 6346
• Processor manufacturer Intel
• Processor family Intel® Xeon®
• Processor cores 16
• Maximum internal memory 6 TB
• Thermal Design Power (TDP) 205 W
• Component for Server/workstation
• Status Launched
• Launch date Q2'21
• Market segment Server
• ECC Yes
• PCI Express slots version 4.0
• Processor lithography 10 nm
• Processor cache 36 MB
• Processor threads 32
• Processor boost frequency 3.6 GHz
• Processor generation 3rd Generation Intel® Xeon® Scalable
• On-board graphics card model Not available
• Discrete graphics card model Not available
• On-board graphics card No
• Discrete graphics card No
• Intel Software Guard Extensions (Intel SGX) Yes
• Embedded options available No
• Intel Trusted Execution Technology Yes
• Intel Virtualization Technology for Directed I/O (VT-d) Yes
• Intel Virtualization Technology (VT-x) Yes
• Intel VT-x with Extended Page Tables (EPT) Yes
• Execute Disable Bit Yes
• Intel 64 Yes
• Processor socket LGA 4189
• Memory channels Octa-channel
• Supported memory types DDR4-SDRAM
• Processor codename Ice Lake
• Intel® Optane™ Memory Ready Yes
• Intel® AES New Instructions (Intel® AES-NI) Yes
• Intel® Hyper Threading Technology (Intel® HT Technology) Yes
• System bus rate 11.2 GT/s
• Processor operating modes 64-bit
• Memory clock speeds supported by processor 3200 MHz
• Memory types supported by processor DDR4-SDRAM
• Maximum internal memory supported by processor 6.14 TB
• Maximum number of PCI Express lanes 64
• Processor ARK ID 212457
• Intel® Turbo Boost Technology 2.0
• Supported instruction sets AVX
  AVX-512
  AVX 2.0
  SSE4.2
• Scalability 2S
• Processor package size 77.5 x 56.5 mm
• Target market Cloud Computing
• Processor base frequency 3.1 GHz
• Intel® Transactional Synchronization Extensions Yes
• Intel® Volume Management Device (VMD) Yes
• Intel® Speed Shift Technology Yes
• Mode-based Execute Control (MBE) Yes
• Intel® Total Memory Encryption Yes
• Servicing status Baseline Servicing
• Intel® Optane™ DC Persistent Memory Supported Yes
• Maximum Enclave Size Support for Intel® SGX 64 GB
• Number of UPI links 3
• Memory speed (max) 3200 MHz
• Tcase 78 °C
• Intel® Crypto Acceleration Yes
• Intel® Resource Director Technology (Intel® RDT) Yes
• Intel® Platform Firmware Resilience Support Yes
• AVX-512 Fused Multiply-Add (FMA) units 2
• Intel® Run Sure Technology Yes
• High priority cores 4
• High priority core frequency 3.2 GHz
• Low priority cores 12
• Low priority core frequency 3 GHz
• Warnings Avoid direct contact with water and high humidity.
• Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes
