PLANET GS-5220-16S8CR network switch Managed L2+ Gigabit Ethernet (10/100/1000) 1U Blue

Datablad

• Storage temperature (T-T) -10 - 70 °C
• Operating temperature (T-T) 0 - 50 °C
• Harmonized System (HS) code 85176990
• Form factor 1U
• AC input voltage 100 - 240 V
• AC input frequency 50 - 60 Hz
• Operating relative humidity (H-H) 5 - 95%
• LED indicators Yes
• Power consumption (typical) 36.2 W
• Stackable No
• DC input voltage 36 - 72 V
• Throughput 95.23 Mpps
• Power supply included Yes
• Storage relative humidity (H-H) 5 - 95%
• Ethernet LAN data rates 10,100,1000 Mbit/s
• Security algorithms SSH
• Input current 0.6 A
• Networking standards IEEE 802.1w
• Rack mounting Yes
• Power over Ethernet (PoE) No
• Reset button Yes
• Web-based management Yes
• Cloud-managed Yes
• Quality of Service (QoS) support Yes
• Multicast support Yes
• Full duplex Yes
• Copper ethernet cabling technology 1000BASE-T
• Jumbo frames support Yes
• VLAN support Yes
• MAC address filtering Yes
• IGMP snooping Yes
• Virtual LAN features Private VLAN
• Access Control List (ACL) Yes
• Auto MDI/MDI-X Yes
• Static route Yes
• Heat dissipation 102.9 BTU/h
• Number of VLANs 4094
• Console port RS-232
• System event log Yes
• Flow control support Yes
• Fiber optic connector SFP
• Fiber ports quantity 24
• Auto-negotiation Yes
• MAC address table 16000 entries
• Installed SFP+ modules quantity 4
• Installed SFP modules quantity 24
• Switch type Managed
• Switch layer L2+
• Port mirroring Yes
• Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
• Basic switching RJ-45 Ethernet ports quantity 8
• Switching capacity 128 Gbit/s
• Link aggregation Yes
• Store-and-forward Yes
• Jumbo frames 10000
• Fiber ethernet cabling technology 100BASE-X
• 10G support No
• Spanning tree protocol Yes
• Authentication MAC-based authentication, Port-based authentication
• Authentication type RADIUS, TACACS+
• DHCP features DHCP snooping
• Half duplex Yes
• Packet buffer memory 16 MB
• Loop protection Yes
• Traffic classification Yes
• Queue scheduling algorithms SP
• SSH/SSL support Yes
• BPDU filtering/protection Yes
• ARP inspection Yes
• Number of multicast groups filtered 255
• Redundant power supply (RPS) support Yes
• Number of static routes 128
• Product colour Blue
• Height 44 mm
• Width 440 mm
• Weight 3.5 kg
• Depth 260 mm
• Housing material Metal
• Certification FCC Part 15 Class A, CE

Särskilda hänvisningar

• ean13 4711605280334
