TP-Link 8-Port Gigabit Desktop/Rackmount Network Switch

Datablad

• Power source AC
• Storage temperature (T-T) -40 - 70 °C
• Operating temperature (T-T) 32 - 104 °F
• Harmonized System (HS) code 85176990
• Package type Box
• Form factor 1U
• AC input voltage 100 - 240 V
• AC input frequency 50 - 60 Hz
• Dimensions (WxDxH) 294 x 180 x 44 mm
• Operating relative humidity (H-H) 10 - 90%
• LED indicators Yes
• Power consumption (typical) 4.3 W
• Quick start guide Yes
• Connectivity technology Wired
• Cables included AC
• Power supply included Yes
• Storage relative humidity (H-H) 5 - 90%
• Maximum data transfer rate 1 Gbit/s
• Networking standards IEEE 802.3u
• Rack mounting Yes
• Power over Ethernet (PoE) No
• Supported network protocols CSMA/CD, TCP/IP
• Bandwidth 16 Gbit/s
• Supported data transfer rates 10/100/1000 Mbps
• Full duplex Yes
• Copper ethernet cabling technology 100BASE-TX
• Jumbo frames support Yes
• Networking features Gigabit Ethernet
• Auto MDI/MDI-X Yes
• Heat dissipation 14.67 BTU/h
• Flow control support Yes
• Auto-negotiation Yes
• MAC address table 4000 entries
• Switch type Unmanaged
• Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
• Basic switching RJ-45 Ethernet ports quantity 8
• Switching capacity 16 Gbit/s
• Store-and-forward Yes
• Jumbo frames 16000
• 10G support No
• Dimensions (W x D x H) (imperial) 248.9 x 157.5 x 43.2 mm (9.8 x 6.2 x 1.7")
• Connectivity LEDs Y
• Product colour Black
• Height 44 mm
• Width 294 mm
• Depth 180 mm
• Package width 400 mm
• Input frequency 50 - 60 Hz
• Package height 80 mm
• Certification FCC, CE, RoHS
• Package weight 1.7 kg
• Package depth 250 mm

Särskilda hänvisningar

• ean13 6935364021573
